Features of GIGABYTE GeForce RTX 4080 Gaming OC 16GB
- NVIDIA Ada Lovelace Streaming Multiprocessors:
Up to 2x performance and power efficiency
- 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
- 3rd Generation RT Cores: Up to 2X ray tracing performance
- Powered by GeForce RTX™ 4080 16GB
- Integrated with 16GB GDDR6X 256-bit memory interface
- WINDFORCE cooling system
- RGB Fusion
- Dual BIOS
- Protection metal back plate
- Anti-sag bracket
- 4 Years Warranty (Online registration required)
WINDFORCE
COOLING SYSTEM
The WINDFORCE cooling system of the GIGABYTE GeForce RTX 4080 Gaming OC 16GB Nvidia graphics card for pc features three 110mm unique blade fans, alternate spinning, 11 composite copper heat pipes, a large vapor chamber directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
SCREEN COOLING
Extended heatsink allows air to pass through, providing better heat dissipation.
ULTRA DURABLE
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
Specifications of GIGABYTE GeForce RTX 4080 Gaming OC 16GB
| Chipset |
GeForce RTX��� 4080 |
| Core Clock |
2535 MHz (Reference Card: 2505MHz) |
| CUDA�� Cores |
9728 |
| Memory Clock |
22.4 Gbps |
| Memory Size |
16GB |
| Memory Bus |
256 bit |
| Memory Type |
GDDR6X |
| Card Bus |
PCI-E 4.0 |
| Resolution |
7���680x4320 |
| Multi-view |
4 |
| Dimension |
L=342 W=150 H=75 mm |
| PCB Form |
ATX |
| DirectX |
1���2 Ultimate |
| OpenGL |
4.6 |
| Recommended PSU |
850 W |
| Power Connectors |
16��� Pin*1 |
| Output |
DisplayPort 1.4a *3
HDMI 2.1 *1
|
| Accessories |
1. Quick guide
2. Warranty registration
3. Anti-sag bracket
4. Anti-sag bracket installation guide
5. One 16 pin to triple 8-pin power adaptor
|
| Warranty |
3+1 Years Warranty (Online registration required) |
| Note* |
Price, feature and specifications are subject to change without notice. |
